Auger Flight , Screw Flight , Helix Flight , Sectional Flight , Helicoid Flight

Auger Flight

 At Bega Screw Conveyor we have one of the most innovative processes that currently exist to offer you refurbishment for screw conveyors such as the auger flight, this complex process allows us to carry out the precise manufacture of our screw flights, offering you a product with diameter and pitch correct, traditionally these pieces are manufactured in a traditional way, but with poor results and poor appearance.



  These auger flight are manufactured from unfolded sheet, to later form them using the aforementioned procedures. A helical conveyor is made up of pitches, these pitches are commonly called auger flight (screw conveyor), which are subsequently joined by means of a welding process to form a screw conveyor of the desired length.



    These screw flights are used as articles or supplies for manufacturers of industrial machinery for material handling or dosing where a screw conveyor is essential, they are also used as a spare part for damaged screw flights.

 We manufacture auger flight in various configurations and shapes, and the main target market is screw conveyor manufacturers, who want to avoid the auger flight manufacturing process and offer their customers a quality product, with auger perfect screw, that do not have problems in the union and have quality control and delivery time.

  The screw flight forming machine has been one of the great developments of the Bega Screw Conveyor brand throughout our 15 years in the market. As our product is developed with our engineering, we have the possibility of offering you practically any measure of Auger Flight in different materials and plate thicknesses. Try us and we will gladly give you attention.





They are used by:







These auger flight (screw conveyor) are manufactured in two rotations, left hand and right hand, the pitch is manufactured in standard, long pitch, short pitch. They are supplied in 3 meter long sections, with or without mounting tube or shaft, as required.



















  • Seed Bulk Handling

  • Feed Wagons

  • Ribbon Mixers

  • Screw Conveyor Horizontal and Inclined

  • Food Handling

  • Fertilizer Handling

  • Sludge Removal

  • Hole Digging

  • Materials Separators

  • Screw Feeder

  • Mine

Types of manufacturing materials:



  • A36 Carbon Steel

  • Hardox 400

  • Hardox 450

  • Hardox 500

  • Stainless Steel (304)

  • Stainless Steel (316)

  • Stainless Steel (Duplex 2205)

Out Diameter Size:



  • Rangos entre 50mm a 4000mm

  • For larger diameters call the factory.







Thickness:



  • 1/8"

  • 3/16 "

  • 1/4 "

  • 5/16"

  • 3/8"

  • 1/2"

  • 3/4"

  • 1"

  • 1-1/2"

  • 2"

  • Para mayores espesores llamar a la fabrica.

Format for ordering Auger Flight

Technical information about our process and tolerances


Bega's Auger Flights (Screw Flights)

Auger Flight SS304 Forming

Auger Flight SS304 Forming

Screw Flight Hardox 500

Screw Flight Hardox 500

Auger Flight

Auger Flight

Auger Flighting

Auger Flighting

Plasma Cutting

Plasma Cutting

Auger Flight Complete

Auger Flight Complete

Screw Flight Packing

Screw Flight Packing

Mini Screw Flight

Mini Screw Flight

Helix Flight SS304

Helix Flight SS304

Measurement Helix Flight

Measurement Helix Flight

Screw Flight Installed

Screw Flight Installed

Screw Flight Polished

Screw Flight Polished

Helicoid Flight Installed

Helicoid Flight Installed

Spiral Flight Polish

Spiral Flight Polish

Measurements Helix Flight

Measurements Helix Flight

Auger Flight Formed

Auger Flight Formed

Screw Flight Installed

Screw Flight Installed

Auger Flight Export

Auger Flight Export

Wide variety of auger flight measurements

Wide variety of auger flight measurements

Perfect Screw Flight

Perfect Screw Flight

Auger Flight SS304 Measurements

Auger Flight SS304 Measurements

Screw Flight perfect Union

Screw Flight perfect Union

Auger Flight (Screw Flight) Manufacture
